Settings for connection dialing and QoS for Call of Duty

Resource Settings for connection dialing and QoS for Call of Duty

Settings for connection dialing and QoS for Call of Duty

Free

It performs the connection marking for the traffic that is established with Call of Duty and a QoS configuration is applied indicating the dedicated bandwidth for its traffic. This configuration cannot be used on an RB balancer.

Compact file conexionCallOfDuty.rsc

Download

#Configuración general de RB mikrotik
/interface bridge
add name=bridge1
/ip pool
add name=pool1 ranges=172.16.1.2-172.16.1.100
/ip dhcp-server
add address-pool=pool1 disabled=no interface=bridge1 name=server1
/ip firewall nat
add action=masquerade chain=srcnat out-interface=ether1
/interface bridge port
add bridge=bridge1 interface=ether5
/ip address
add address=172.16.1.1/24 interface=bridge1 network=172.16.1.0
/ip dhcp-client
add disabled=no interface=ether1
/ip dhcp-server network
add address=172.16.1.0/24 gateway=172.16.1.1 netmask=24

#Con estas reglas marcaremos la conexión de Call of duty mobile
/ip firewall mangle
add action=mark-connection chain=prerouting new-connection-mark=call_of_duty_conn passthrough=yes port=\
    8013,10000-10019,18082,50000,65010,65050 protocol=tcp
add action=mark-connection chain=prerouting new-connection-mark=call_of_duty_conn passthrough=yes port=\
    7085-7995,8700,9030,10010-10019,17000-20100 protocol=udp

#Esta regla tomará la conexión y marcaremos el paquete para poder añadirlo al queue tree
add action=mark-packet chain=prerouting connection-mark=call_of_duty_conn new-packet-mark=call_of_duty_pkt passthrough=no

#Las siguientes reglas toman el paquete de Call of duty mobile para ayudarnos a crear un QoS,
#la prioridad y el max limit se pueden cambiar por el que uno requiera.
/queue type
add kind=pcq name=DOWN pcq-classifier=dst-address
add kind=pcq name=UP pcq-classifier=src-address
/queue tree
add max-limit=50M name="QoS down" parent=bridge1 queue=DOWN
add max-limit=50M name="QoS up" parent=ether1 queue=UP
add max-limit=3M name=call_of_duty_down packet-mark=call_of_duty_pkt parent="QoS down" priority=4 queue=DOWN
add max-limit=3M name=call_of_duty_up packet-mark=call_of_duty_pkt parent="QoS up" priority=5 queue=UP
