Settings for connection dialing and QoS for Heroes Evolved

Free

It performs connection marking for the traffic that is established with Heroes Evolved during the game and a QoS configuration is applied indicating the dedicated bandwidth for its traffic. This configuration cannot be used on an RB balancer.

Compact file mcpHeroesEvolved.rsc

Download

#Configuración general de RB mikrotik
/interface bridge
add name=bridge1
/ip pool
add name=pool1 ranges=172.16.1.2-172.16.1.100
/ip dhcp-server
add address-pool=pool1 disabled=no interface=bridge1 name=server1
/ip firewall nat
add action=masquerade chain=srcnat out-interface=ether1
/interface bridge port
add bridge=bridge1 interface=ether5
/ip address
add address=172.16.1.1/24 interface=bridge1 network=172.16.1.0
/ip dhcp-client
add disabled=no interface=ether1
/ip dhcp-server network
add address=172.16.1.0/24 gateway=172.16.1.1 netmask=24

#Con estas reglas marcaremos la conexión de Heroes Evolved
/ip firewall mangle
add action=mark-connection chain=prerouting new-connection-mark=her_evo_conn passthrough=yes port=3010-3019 protocol=tcp
#Esta regla tomará la conexión y marcaremos el paquete para poder añadirlo al queue tree
add action=mark-packet chain=prerouting connection-mark=her_evo_conn new-packet-mark=her_evo_pkt passthrough=no

#Las siguientes reglas toman el paquete de Heroes Evolved para ayudarnos a crear un QoS,
#la prioridad y el max limit se pueden cambiar por el que uno requiera.
/queue type
add kind=pcq name=DOWN pcq-classifier=dst-address
add kind=pcq name=UP pcq-classifier=src-address
/queue tree
add max-limit=50M name="QoS down" parent=bridge1 queue=DOWN
add max-limit=50M name="QoS up" parent=ether1 queue=UP
add max-limit=10M name=her_evo_down packet-mark=her_evo_pkt parent="QoS down" priority=4 queue=DOWN
add max-limit=5M name=her_evo_up packet-mark=her_evo_pkt parent="QoS up" priority=5 queue=UP

Compact file mcHeroesEvolved.rsc

Download

#Con estas reglas marcaremos la conexión de Heroes Evolved
/ip firewall mangle
add action=mark-connection chain=prerouting new-connection-mark=her_evo_conn passthrough=yes port=3010-3019 protocol=tcp
#Esta regla tomará la conexión y marcaremos el paquete para poder hacer QOS, bloqueo o procesarlo de la manera en la que se requiera en la red
add action=mark-packet chain=prerouting connection-mark=her_evo_conn new-packet-mark=her_evo_pkt passthrough=no
